Lot No. 2011

ZDAS QKK 35 Rail-Bound Forging Manipulator (2005)

Year: 2005
Make: ZDAS
Model: QKK 35
Capacity: 40 TonToggle Moment: 80kNm

min./max. Gripping diam.: 310/1.600 mm

min./max. Axis height of the Tongs: 950/2.350 mm

Tilting upward: 8 Degr.

Tilting down ward: base

Speed vert. travel: 110 mm/sec.

Tongs traverse travel approx.: 150 mmmax.

Rotation speed Tongs: 12 rpmmax. Speed: 40 M/min

Rail centre distance: 4.000 mm

Accuracy catching the ingot approx.: 5 mm

Installed Power: 180 kW

Weight Kg.: 132000

***COMBINATION LOTS: together with lot 2010
