7x Stainless Steel Vessels
Equipment: 1
Volume m³: 20.9
Height/Length mm: 7031
Diameter mm: 2000
Material of Construction: Duplex Stainless Steel
Design Pressure Max. Bar: 3.2
Design Temperature Max. °C: 230
Service: Naphtha
Year of construction: 2020
Design Code ANSI / DIN: DIN
Comment:
Picture: Pic1, Pic2
Equipment: 2
Volume m³: 0.05
Height/Length mm: 520
Diameter mm: 324
Material of Construction: Stainless Steel
Design Pressure Max. Bar: 10
Design Temperature Max. °C: 80
Service: QR-Slops
Year of construction: 2005
Design Code ANSI / DIN: DIN
Comment:
Equipment: 3
Volume m³: 0.05
Height/Length mm: 520
Diameter mm: 324
Material of Construction: Stainless Steel
Design Pressure Max. Bar: 10
Design Temparature Max. °C: 80
Service: QR-Slops
Year of construction: 2005
Design Code ANSI / DIN: DIN
Comment:
Equipment: 4
Volume m³: 5.1
Height/Length mm: 4230
Diameter mm: 1300
Material of Construction: Stainless Steel
Design Pressure Max. Bar: 4.2
Design Temperature Max. °C: 343
Service: HC Reflux
Year of construction: 2015
Design Code ANSI / DIN: DIN
Comment:
Picture: Pic1, Pic2
Equipment: 5
Volume m³: 3
Height/Length mm: 3507
Diameter mm: 1100
Material of Construction: Stainless Steel
Design Pressure Max. Bar: 4.9
Design Temperature Max. °C: 310
Service: HC Reflux
Year of construction: 2003
Design Code ANSI / DIN: DIN
Comment:
Picture: Pic1, Pic2
Equipment: 6
Volume m³: 1.34
Height/Length mm: 2675
Diameter mm: 1000
Material of Construction: Duplex Stainless Steel
Design Pressure Max. Bar: Atm.
Design Temperature Max. °C: 125
Service: Steam/Water
Year of construction: 2020
Design Code ANSI / DIN: DIN
Comment:
Equipment: 7
Volume m³: 5.1
Height/Length mm: 5240
Diameter mm: 1116
Material of Construction: Stainless Steel
Design Pressure Max. Bar: 3.5
Design Temperature Max. °C: 250
Service: Sour water
Year of construction: 2010
Design Code ANSI / DIN: DIN
Comment:
Picture: Pic1
